Revival 640 Offshore

$0.00
* Sail Away
Send an Enquiry
61eee9_0313da9290144a2884f15bba20cfca60_mv2_d_2918_1948_s_2
61eee9_1875505429224bb7b8aa96e14512be82_mv2_d_2919_1948_s_2
61eee9_683ecab18d894f5780be86b1adff4348_mv2_d_2793_1864_s_2
61eee9_6ac2845dd42b4e5180f05c841d7337bd_mv2_d_2352_1568_s_2
61eee9_8d2fac3766ae4675ac268e0d3ea328e0_mv2_d_3264_2448_s_4_2
61eee9_c15d04c1828e46a58821f16cefda1ecf_mv2_d_3008_2008_s_2
61eee9_e19273f6c2a345e59d46050fc586d7c2_mv2_d_3264_2448_s_4_2
Click to zoom / enlarge this image
61eee9_0313da9290144a2884f15bba20cfca60_mv2_d_2918_1948_s_2
61eee9_1875505429224bb7b8aa96e14512be82_mv2_d_2919_1948_s_2
61eee9_683ecab18d894f5780be86b1adff4348_mv2_d_2793_1864_s_2
61eee9_6ac2845dd42b4e5180f05c841d7337bd_mv2_d_2352_1568_s_2
61eee9_8d2fac3766ae4675ac268e0d3ea328e0_mv2_d_3264_2448_s_4_2
61eee9_c15d04c1828e46a58821f16cefda1ecf_mv2_d_3008_2008_s_2
61eee9_e19273f6c2a345e59d46050fc586d7c2_mv2_d_3264_2448_s_4_2

Mechanical Steering

Steering

6.4 metres

Length

Fibreglass

Hull Material

Mono

Hull Type

Details Specifications Features & Options
Boat Details
  • Make: Revival
  • Name: 640 Offshore
  • Model Number: 640 Offshore
  • Year: 2025
  • Length: 6.4 metres
  • Width: 2.48 metres
  • Dry Weight: 2175 kg
  • Hull Material: Fibreglass
  • Hull Type: Mono
  • Passenger Capacity: 8
  • Boat Usage: Fishing
  • Steering: Mechanical Steering
  • Warranty: Contact Dealer

Revival's R640 OffShore redefines the the offshore trailer boat landscape with a 6.5m full-figured hull that treats rough conditions with contempt while treating your family and crew to a soft, dry and quiet ride. Equal parts, mini game boat and family cruiser, this big hull demands respect. Undeniably tough, yet refined and sophisticated, the R640 OffShore and Hard Top variants proves that Hard-Core CAN have a soft side!

  • Hull Length (mm)... 6400mm

    Hull Beam (mm)... 2480mm

    Transom Deadrise... 21 degrees

    Transom Height (inches)... 25"/XL

    Height on Trailer to top of Windscreen... 2450mm

    Overall Length on Trailer (mm)... 8200mm

    Draft (mm)... 300mm

    Hull Weight (kg) - dry... 1200kg

    BMT Weight (kg) - dry... 2175kg* (Subject to variation)

    Fuel Capacity (lt)... 200lt

    Number of People... 8 Adults

    Horsepower... 150 - 225hp

    Max Outboard Weight (kg)... 290kg

    Estimated Cruise Speed (kph) w/Mid-Range hp... 45kph

    Estimated WOT Speed (kph) w/Mid-Range hp... 72kph

    Internal Cockpit Length (mm)... 1800mm

    Internal Cockpit Beam (mm)... 2000mm
  • Anchor Storage Compartment with Large Front Opening Hatch.
  • Backrest and Bunks in Cabin - Upholstered Vinyl.
  • Bilge Pump Hose and Outlet.
  • Bollard Split - Stainless Steel.
  • Bow Roller - Stainless Steel.
  • Cabin Headlining.
  • Carpeted Floor and Sides - Glued.
  • Coaming Lights (2).
  • Cockpit Side Pockets - Fibreglass gel coated white.
  • Composite Fibreglass Stringer System Moulded Liner.
  • Hydraulic Steering with Sports Steering Wheel.
  • Hull and Deck - All White Gelcoat with Edition Specific Stripes and Graphics.
  • Large Forward Storage/Casting Area with Open and Concealed Storage Bins.
  • Mechanical Steering.
  • Navigation Lights.
  • Padded transom Backrest Rear of Cockpit with Removable Fold-Down Rear Lounge.
  • Padded Side Pockets in Cabin - Vinyl.
  • Panic Rail for Passenger - Stainless Steel.
  • Port-side Coaming Storage Compartment.
  • Port and Starboard Recessed Cockpit Grab Rails.
  • Rear Starboard-Side Bait Well that Drains Overboard - Not Plumbed.
  • Rear Pop-Up Cleats - Stainless Steel (2).
  • Rear Door/Step.
  • Rear Tow Eyes - Stainless Steel (2).
  • Split Bowrails - Stainless Steel.
  • Standard Plastic Rear Rod Holders (2).
  • Swivel Bucket Seats on Fixed Pedestals with Seat Slides (Non-Flip Up Seats).
  • Twin-Core Tinned Wiring to Dash.
  • Under bunk Cabin Storage with Vinyl-Upholstered Bunk Cushions.
  • Underfloor Fuel Tank 200L with Breathers that Drain to Engine Well, Fuel Sender, Filler Cap in Engine Well.
  • Underfloor Kill Tank/ Storage Locker - Moulded Fibreglass (Approx. 200lt).
  • Water-Resistant Switch Panel.
  • Windscreen Grab Rail.
  • Windscreen Toughened Glass Front Screen with Durable Perspex Sides.
